Belfab

J Series – Dust collection

The Belfab J series dust collectors are designed for a range of dust loads from moderate to heavy, or industrial capacities, and are capable of collecting dust particles ranging from coarse to mixed sizes.

These entry-level units are generally recommended for woodworking applications involving one or two machines in a small-size shop environment, or as a dedicated “stand-alone” solution within a larger facility. The various models can be configured with various dust removal solutions ranging from the standard plastic bags, to the 55 gallon steel or plastic drums, or to Belfab’s patented tilt truck. With space saving in mind most models of the J series are capable of fitting into a 4 sq. ft. - 8 sq. ft. area.

See which model best fits your needs.

These entry-level units are generally recommended for woodworking applications involving one or two machines in a small-size shop environment, or as a dedicated “stand-alone” solution within a larger facility. The various models can be configured with various dust removal solutions ranging from the standard plastic bags, to the 55 gallon steel or plastic drums, or to Belfab’s patented tilt truck. With space saving in mind most models of the J series are capable of fitting into a 4 sq. ft. - 8 sq. ft. area.

See which model best fits your needs..

http://www.stilesmachinery.com/includes/files/assets/images/medium/1271882808_belfab-jdw.jpg



JJ

JLW

JDW

JNBM-OP

Blower Motor (STD)

2 hp

3 hp

5 hp

7.5 hp

CFM Capacity

1,080

1,400

2,500

3,500

Filtration Surface

32 ft²

42 ft²

84 ft²

165 ft²

Disposal Capacity

7 cu/ft

9 cu/ft

18 cu/ft

18 cu/ft

Disposal Options

Bags, arrel

Bags/ Barrel

Bags, Barrel, Tilt Truck

Bags, Barrel, Tilt Truck

Inlet Diameter

6"

7"

9"

10"

Machine Dimensions

21" x 29" x 80"

44" x 24" x 130"

44" x 48" x 130"

44" x 48" x 130"

Weight

120 lbs.

150 lbs.

300 lbs.

325 lbs.

Sound Pressure

81 dB

85 dB

86 dB

87 dB
