Trimming, Buffing & Cleaning Systems

http://www.stilesmachinery.com/images/shim.gif

Gottschild systems are used for trimming and buffing/cleaning of rigid thermofoil laminated furniture components.

The Gottschild CS 2001 is a trimming machine for foil laminated 3-D components. The overhead trimming system removes the entire overlapping PVC foil from MDF components. The CS 2001 automatically recognizes the size and thickness of components, which makes random feeding possible. The BSD 2000 is a buffing machine for removing the excess glue on the melamine side (back) of the panel. The BSD 2000 uses a four- or eight-head rotating brush system to remove glue overspray from the back of each panel and is able to sense each length and width. The CBS 3800 combines both trimming and buffing in one machine. Combining the trimming and buffing functions in one machine allows for a more compact machine design in a single process, saving you valuable floor space, manual labor, and money.

Click here to learn more about Wemhöner membrane presses.

Jump to: BSD 2000   |  CS 2001  |  CBS 3800

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

BSD 2000

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

Heesemann Impression Widebelt Sander

http://www.stilesmachinery.com/images/shim.gif

The Gottschild BSD 2000 is a buffing and cleaning system for foil coated, 3-D furniture front panels. The four- or eight-head rotating brush system removes the glue overspray from the back of the furniture front panels, achieving an optimum texture of edges at the same time. This result is achieved, because the disk brushes are put on the back of the front panels with pneumatically controlled pressure and clean them. Any remaining loose glue is removed by a spiral brush. The BSD 2000 has been designed for a capacity of up to 3800 parts per shift, making the machine the perfect buffing system for medium and large-scale productions. The BSD 2000 has been equipped with an automatic recognition of size and thickness of the furniture panels, enabling easy adaptation to random loading, without losing time in throughfeed operation. Due to the flexible control system, there is the possibility of buffing rectangular and contour parts. The low-maintenance brushes are very durable, ensuring low production costs.

http://www.stilesmachinery.com/images/pdf_gottschild_bsd_2000.jpg

http://www.stilesmachinery.com/images/shim.gif

Download a PDF brochure
(229k, Acrobat Reader required)

For more information
complete our online request form or call Dave Haire at 416-951-9505.

http://www.stilesmachinery.com/images/shim.gif

features
• Four- or Eight-head rotating brushing system
• Spiral brush removes loose glue residues
• Angled feed roller conveyor with component staggering
• Modem for remote maintenance
• Adapts automatically to size and thickness of components, making random feeding possible

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

CS 2001

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

Heesemann MFA-6 Widebelt Sander

http://www.stilesmachinery.com/images/shim.gif

The Gottschild CS 2001 is a trimming machine for foil laminated, 3-D furniture components. The proven overhead trimming system on the CS 2001 removes the entire overlapping PVC foil from MDF furniture components. This overhead trimmer is designed to handle continuous 3-shift operation, with a capacity of 7.5 parts per minute and 3600 parts per shift. This makes the CS 2001 the perfect trimming system for large producers of rectangular furniture components. The CS 2001 automatically recognizes the size and thickness of furniture components, making random feeding possible. The two-head trimming system, with patented round knives, quickly and efficiently processes the lengthwise edges of the workpiece in throughfeed operation.

http://www.stilesmachinery.com/images/pdf_gottschild_cs_2001.jpg

http://www.stilesmachinery.com/images/shim.gif

Download a PDF brochure
(470k, Acrobat Reader required)

For more information
complete our online request form or call Dave Haire at 416-951-9505.

http://www.stilesmachinery.com/images/shim.gif

features
• Two-head rotating knife trimming system
• Angled feed roller conveyor with component staggering
• Modem for remote maintenance

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

CBS 3800

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

http://www.stilesmachinery.com/images/shim.gif

Heesemann LSM-8 Widebelt Sander

http://www.stilesmachinery.com/images/shim.gif

The Gottschild CBS 3800 is a combined trimming and buffing machine for foil laminated, 3-D furniture components. The proven overhead trimming system for removing the entire overlapping PVC foil from MDF furniture components is perfectly complemented by a brushing unit. The four- or eight-head rotating brush system removes the glue overspray from the backs of the 3-D furniture components, as well as rounds down the sharp foil edges for optimum results. Combining the trimming and buffing units allows for a single process. The CBS 3800 can produce up to 2400 panels per shift, utilizing both trimming and buffing functions. The two-head trimming system, with patented round knives, quickly and efficiently processes the lengthwise edges of the workpiece in throughfeed operation. The flexible control system offers the possibility of running the trimming and cleaning functions with this separate control function; the brush station can also clean contoured parts. The low-maintenance brushes are very durable, ensuring low production costs.

http://www.stilesmachinery.com/images/pdf_gottschild_cbs_3800.jpg

http://www.stilesmachinery.com/images/shim.gif

Download a PDF brochure
(283k, Acrobat Reader required)

For more information
complete our online request form or call Dave Haire at 416-951-9505.
